Product Description
+−
Inlet Size
1-1/8"
Style

GPM
1.4
Gallons
Inlet Size
1-1/8"
Style
Condensation
GPM
1.4 Gallons
Features
Features
- Barnes BC-15 - 1/50 HP Condensate Pump
- For residential and commercial applications
- For water removal from high efficiency furnaces, AC equipment and dehumidifiers
- High Impact ABS Tank
- Corrosion-resistant and impact-resistant construction
- Built-In Automatic Float Switch
- Allows this pump to run automatically when reservoir is full
- Built-In Check Valve
- Removable design, allows for easier servicing
- (3) 1-1/8" Intake Holes
- Meets the needs of a wide variety of applications
- 3/8" O.D. Barbed Outlet/Discharge Adapter
- Allows for easier installation
- 6' Power Cord w/ Ground
- Requires a hardwired connection
- 150F Maximum Fluid Temperature
- 2-Year Limited Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
1
Power Cord Length
6 Feet
Pump
Gallons Per Minute
1.4 Gallons
Inlet Diameter
1-1/8"
Outlet Diameter
3/8"
Housing Material
Thermoplastic
Impeller Material
Plastic
Handles Solids
No
Total Head Lift
15 Feet
Built-in check Valve
Yes
Engine
Horsepower
0.02 hp
Overview
Weight
5 Pounds
Consumer Warranty
2 Years
Product Length
11.13 Inches
Product Width
6.5 Inches
Product Height
5 Inches
Inlet Size
1-1/8"
Style

GPM
1.4
Gallons
Inlet Size
1-1/8"
Style
Condensation
GPM
1.4 Gallons
Features
Features
- Barnes BC-15 - 1/50 HP Condensate Pump
- For residential and commercial applications
- For water removal from high efficiency furnaces, AC equipment and dehumidifiers
- High Impact ABS Tank
- Corrosion-resistant and impact-resistant construction
- Built-In Automatic Float Switch
- Allows this pump to run automatically when reservoir is full
- Built-In Check Valve
- Removable design, allows for easier servicing
- (3) 1-1/8" Intake Holes
- Meets the needs of a wide variety of applications
- 3/8" O.D. Barbed Outlet/Discharge Adapter
- Allows for easier installation
- 6' Power Cord w/ Ground
- Requires a hardwired connection
- 150F Maximum Fluid Temperature
- 2-Year Limited Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
1
Power Cord Length
6 Feet
Pump
Gallons Per Minute
1.4 Gallons
Inlet Diameter
1-1/8"
Outlet Diameter
3/8"
Housing Material
Thermoplastic
Impeller Material
Plastic
Handles Solids
No
Total Head Lift
15 Feet
Built-in check Valve
Yes
Engine
Horsepower
0.02 hp
Overview
Weight
5 Pounds
Consumer Warranty
2 Years
Product Length
11.13 Inches
Product Width
6.5 Inches
Product Height
5 Inches
Product Specs
+−
Specifications
Motor
Voltage
120 Volt
Running Amps
1
Power Cord Length
6 Feet
Pump
Gallons Per Minute
1.4 Gallons
Inlet Diameter
1-1/8"
Outlet Diameter
3/8"
Housing Material
Thermoplastic
Impeller Material
Plastic
Handles Solids
No
Total Head Lift
15 Feet
Built-in check Valve
Yes
Engine
Horsepower
0.02 hp
Overview
Weight
5 Pounds
Consumer Warranty
2 Years
Product Length
11.13 Inches
Product Width
6.5 Inches
Product Height
5 Inches
