Tsurumi TD6-300 - 85 GPM (3") Diaphragm Pump w/ Honda GX Engine
Model: TD6-300
+
Share This Product
-
Product Description
-
Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Inlet Size
3"
Style

GPM
85
Gallons
Engine
Inlet Size
3"
Style
Diaphragm
GPM
85 Gallons
Engine
Honda GX
Features
Features
- Tsurumi 3" Diaphragm Pump
- Ideal for muddy, slurry and thick liquids (high solid content)
- Handles solids up to 1-5/8" diameter & Maximum Temperature 180°F
- Commercial Grade 118cc Honda OHV GX120 4-Cycle Engine
- Provides easy starting, excellent torque & fuel efficiency
- Protected By Honda Oil Alert® Warning System
- Helps to prevent engine seizure due to a low oil condition
- 2-Stage, Forged Gear Driven Transmission
- Heavy-duty design, operates pump @ 60-strokes per minute
- Sand Cast Aluminum Construction
- Helps reduce weight while still being a very durable pump
- Thermoplastic Santoprene Diaphragm
- Provides extended "wear" life for more pumping and less maintenance
- Built-In Check Valve For Faster Priming
- Helps decrease priming time, once initial prime is created
- Handle & Wheel Kit
- Balanced design makes it easy to transport over uneven terrain
- 90° Rotatable base allows for maximum ease-of-use
- Modular Component Design
- Allows for easier maintenance and cleanout
- Also Includes :
- 3" Steel Suction Strainer & (2) NPT Nipples
- 2-Year Warranty
Specifications
Pump
Gallons Per Minute
85 Gallons
Inlet Diameter
3"
Outlet Diameter
3"
Pump Head Material
Aluminum
Housing Material
Aluminum
Solids Handling Size
1.625 inch
Handles Solids
Yes
Suction Head
20 Feet
Total Head Lift
25 Feet
Discharge Port Size
3 Inch
Built-in check Valve
Yes
Submersible
No
Engine
Engine Brand
Honda GX
Starting System
Recoil Start
Engine Cycles
4-Cycle
Low Oil Shutdown
Yes
CC
118 cc
Fuel Tank Size
.52 Gallons
Run Time
2 Hours
Accessories
Strainer
Yes
Lifting Hook
Yes
Wheel Kit
Yes
Overview
Weight
175 Pounds
Made in USA
No
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
43.4 Inches
Product Width
26.4 Inches
Product Height
23.4 Inches
Inlet Size
3"
Style
