Pacer SE3LLHYC - 280 GPM (3") Hydraulic Drive Water Pump
Pacer SE3LLHYC - 280 GPM (3") Hydraulic Drive Water Pump
+
Share This Product
-
Product Description
-
1Reviews
-
1Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Inlet Size
3"
Style
GPM
280
Gallons
Inlet Size
3"
Style
Dewatering
GPM
280 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- S-Series 3" Multi-Purpose Hydraulic Drive Pump
- Designed for agricultural, transfer & dewatering applications
- Requires 3-HP @ 3450 RPM
- Hydraulic Fluid @ 9 GPM & 750 PSI fluid pressure required
- 50 PSI Gauge reading @ 3450 RPM
- Hydraulics- 9gpm, 1200psi at 3450rpm to achieve 280gpm water flow
- Hydraulic pump fittings – 5/8 tube 7/8 – 14UNF-2B thread SAE10
- Glass-Reinforced Polyester Housing, Volute & Impeller
- For use w/ water, salt water, waste water, mild acids & bases
- Standard EPDM Elastomers (O-Rings & Gasket)
- Compatible with many agricultural chemicals
- EPDM Fitted Stainless Steel Shaft Seal w/ Carbon-Ceramic Faces
- Extends the useful life of the pump
- Internal & External Stainless Steel Fasteners
- High quality components that are built to last
- Includes Pressure Gauge
- Easily obtain the correct operating speed for optimal performance
Specifications
Pump
Gallons Per Minute
280 Gallons
Inlet Diameter
3"
Outlet Diameter
3"
Self Priming
Yes
Pump Head Material
Glass-Reinforced Polyester
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Ceramic Carbon
Impeller Material
Plastic
Handles Solids
No
Suction Head
25 Feet
Total Head Lift
80 Feet
Submersible
No
Engine
Continuous Operation
Yes
Horsepower
3 hp
Accessories
Strainer
Sold Separately
Hose Couplings
No
Float Switch
No
Hose
Sold Separately
Hose Bands
No
Lifting Hook
No
Transport Handle
Yes
Wheel Kit
No
Overview
Weight
16 Pounds
Consumer Warranty
1 Year
Inlet Size
3"
Style
GPM
280
Gallons
Inlet Size
3"
Style
Dewatering
GPM
280 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- S-Series 3" Multi-Purpose Hydraulic Drive Pump
- Designed for agricultural, transfer & dewatering applications
- Requires 3-HP @ 3450 RPM
- Hydraulic Fluid @ 9 GPM & 750 PSI fluid pressure required
- 50 PSI Gauge reading @ 3450 RPM
- Hydraulics- 9gpm, 1200psi at 3450rpm to achieve 280gpm water flow
- Hydraulic pump fittings – 5/8 tube 7/8 – 14UNF-2B thread SAE10
- Glass-Reinforced Polyester Housing, Volute & Impeller
- For use w/ water, salt water, waste water, mild acids & bases
- Standard EPDM Elastomers (O-Rings & Gasket)
- Compatible with many agricultural chemicals
- EPDM Fitted Stainless Steel Shaft Seal w/ Carbon-Ceramic Faces
- Extends the useful life of the pump
- Internal & External Stainless Steel Fasteners
- High quality components that are built to last
- Includes Pressure Gauge
- Easily obtain the correct operating speed for optimal performance
Specifications
Pump
Gallons Per Minute
280 Gallons
Inlet Diameter
3"
Outlet Diameter
3"
Self Priming
Yes
Pump Head Material
Glass-Reinforced Polyester
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Ceramic Carbon
Impeller Material
Plastic
Handles Solids
No
Suction Head
25 Feet
Total Head Lift
80 Feet
Submersible
No
Engine
Continuous Operation
Yes
Horsepower
3 hp
Accessories
Strainer
Sold Separately
Hose Couplings
No
Float Switch
No
Hose
Sold Separately
Hose Bands
No
Lifting Hook
No
Transport Handle
Yes
Wheel Kit
No
Overview
Weight
16 Pounds
Consumer Warranty
1 Year
Product Specs
+−
Specifications
Pump
Gallons Per Minute
280 Gallons
Inlet Diameter
3"
Outlet Diameter
3"
Self Priming
Yes
Pump Head Material
Glass-Reinforced Polyester
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Ceramic Carbon
Impeller Material
Plastic
Handles Solids
No
Suction Head
25 Feet
Total Head Lift
80 Feet
Submersible
No
Engine
Continuous Operation
Yes
Horsepower
3 hp
Accessories
Strainer
Sold Separately
Hose Couplings
No
Float Switch
No
Hose
Sold Separately
Hose Bands
No
Lifting Hook
No
Transport Handle
Yes
Wheel Kit
No
Overview
Weight
16 Pounds
Consumer Warranty
1 Year
Product Q&A
(1)
+−
Search Product Q&A's
Answered by Jim, the Water Pump Expert
+−
We are a greenhouse outfit. We have a reservoir and are hooked up to a Water Utility. We fill the reservoir and have electrical capacity with the electrical pumps however in case of an electrical outage we would have a problem. We want to get a backup water pump to pull the water from the reservoir in case of an emergency. The line going into the main water supply line is PVC and is 6" and also runs through some sand media filters. Our normal working PSI is 30 to 45 PSI and if we wanted just to "maintain" during an electrical outage we would run about 100 to 150 gpm at the 30 to 45 PSI (we usually run around 300 gpm). Our reservoir depth is about 15 feet so the suction tube is above the bottom it is about 12 to 13 foot. I was wondering what your recommendation would be we have 60 hp to 80 hp tractors with PTO and hydraulics
Bob Suzuki
from California
January 13, 2014
Answer
you might look at the Honda 134 GPM (2") High Pressure Water Pump, model WH20 or the TrunkPump 180 GPM (2") High Pressure PTO Water Pump, model TP-2PTP. Another option might be to install a STANDBY GENERATOR. Of course, you would need to know the wattage requirements for correct sizing.
