Pacer SE2FLPE - 160 GPM (2") Plastic Pedestal Mounted Water Pump

Pacer SE2FLPE - 160 GPM (2") Plastic Pedestal Mounted Water Pump
Model: SE2FL PE
$224.99
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping &
Tax-Free (Except IL)
Factory-Direct
Ships in 2-5 Business Days
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Free Shipping
Free Shipping
  • Product Description
  • 3
    Reviews
  • 2
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Inlet Size
2"
Style
Dewatering Pumps
GPM
160
Gallons
Features
Features
  • S-Series 2" Multi-Purpose Pump Head
  • Designed for agricultural, transfer & dewatering applications
  • Plastic Pedestal w/ Carbon-Steel Shaft For Flexible Coupling
  • Compatible w/ electric motors or gas engines
  • Required Power
  • 3-HP electric motors (3450 RPM)
  • 3-HP gas engines (3600 RPM)
  • Glass-Reinforced Polyester Housing, Volute & Impeller
  • For use w/ water, salt water, waste water, mild acids & bases
  • Standard EPDM Elastomers (O-Rings & Gasket)
  • Compatible with many agricultural chemicals
  • EPDM Fitted Stainless Steel Shaft Seal w/ Carbon-Ceramic Faces
  • Extends the useful life of the pump
  • Internal & External Stainless Steel Fasteners
  • High quality components that are built to last
  • All S series self-priming pumps use a shaft
Specifications
Engine
Continuous Operation
Yes
Pump
Gallons Per Minute
160 Gallons
Inlet Diameter
2"
Outlet Diameter
2"
Self Priming
Yes
Pump Head Material
Glass-Reinforced Polyester
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Ceramic Carbon
Impeller Material
Plastic
Handles Solids
No
Suction Head
25 Feet
Total Head Lift
115 Feet
Maximum PSI
50
Submersible
No
Accessories
Strainer
Sold Separately
Hose
Sold Separately
Hose Couplings
No
Hose Bands
No
Transport Handle
Yes
Wheel Kit
No
Overview
Made in USA
Yes
Weight
13 Pounds
Consumer Warranty
1 Year

Inlet Size
2"
Style
Dewatering Pumps
GPM
160
Gallons
Features
Features
  • S-Series 2" Multi-Purpose Pump Head
  • Designed for agricultural, transfer & dewatering applications
  • Plastic Pedestal w/ Carbon-Steel Shaft For Flexible Coupling
  • Compatible w/ electric motors or gas engines
  • Required Power
  • 3-HP electric motors (3450 RPM)
  • 3-HP gas engines (3600 RPM)
  • Glass-Reinforced Polyester Housing, Volute & Impeller
  • For use w/ water, salt water, waste water, mild acids & bases
  • Standard EPDM Elastomers (O-Rings & Gasket)
  • Compatible with many agricultural chemicals
  • EPDM Fitted Stainless Steel Shaft Seal w/ Carbon-Ceramic Faces
  • Extends the useful life of the pump
  • Internal & External Stainless Steel Fasteners
  • High quality components that are built to last
  • All S series self-priming pumps use a shaft
Specifications
Engine
Continuous Operation
Yes
Pump
Gallons Per Minute
160 Gallons
Inlet Diameter
2"
Outlet Diameter
2"
Self Priming
Yes
Pump Head Material
Glass-Reinforced Polyester
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Ceramic Carbon
Impeller Material
Plastic
Handles Solids
No
Suction Head
25 Feet
Total Head Lift
115 Feet
Maximum PSI
50
Submersible
No
Accessories
Strainer
Sold Separately
Hose
Sold Separately
Hose Couplings
No
Hose Bands
No
Transport Handle
Yes
Wheel Kit
No
Overview
Made in USA
Yes
Weight
13 Pounds
Consumer Warranty
1 Year
Product Specs
+
Specifications
Engine
Continuous Operation
Yes
Pump
Gallons Per Minute
160 Gallons
Inlet Diameter
2"
Outlet Diameter
2"
Self Priming
Yes
Pump Head Material
Glass-Reinforced Polyester
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Ceramic Carbon
Impeller Material
Plastic
Handles Solids
No
Suction Head
25 Feet
Total Head Lift
115 Feet
Maximum PSI
50
Submersible
No
Accessories
Strainer
Sold Separately
Hose
Sold Separately
Hose Couplings
No
Hose Bands
No
Transport Handle
Yes
Wheel Kit
No
Overview
Made in USA
Yes
Weight
13 Pounds
Consumer Warranty
1 Year
Reviews
(3)
+
Pacer SE2FL PE Reviews & Ratings
Product Q&A
(2)
+
Hi Jim Is it okay to have the input 2 inch in and reduce the output to a 1 1/2? that would probably increase the PSI a little bit more too, right? or do I have to match both input and output with the same size hose? Thank you.
Marc D
from Minnesota
January 22, 2014
Read Response +
Answer
It is always recommended that you use the same diameter hose/piping as the suction and discharge ports on the pump. While it is sometimes necessary to reduce that diameter, it is NOT recommended that you do so by more than one size. In this case, 1-1/2" hose or piping would be the maximum reduction, While you may see an increased pressure due to the reduced piping, the pump will also see an increased backpressure on the pump. The more you reduce the hose/piping diameter, the more you increase this backpressure AND increase premature pump failure that would NOT be covered under warranty.
Hide Response -
Can I drive the Pacer SE2FLPE with a variable speed motor to get variable flow rate. Normally I need 20 GPM for water filtering and occasionally more when vacuuming a swimming pool.
Orest Storoshchuk
from Michigan
July 20, 2013
Read Response +
Answer
This pump will operate from 3450 rpm down to 1725 rpm. Below 1725 and you may not get anything. At 3450 rpm the pump requires a minimum of 3hp, at 1725 it requires at least a hp motor.
Please note that the slower the motor speed the less pressure and consequently less pumping distance.
Hide Response -
