Little Giant WGFP-200 - 250 PGM 2-HP (3") Submersible Stainless Steel Water Feature Pump (19' Cord - Bare Lead) (230V)
Model: 566072
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
$898.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Free to Lower 48 States
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States

Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Inlet Size
N/A
Style
GPM
250
Gallons
Inlet Size
N/A
GPM
250 Gallons
Features
Features
  • Little Giant WPG Series Submersible Pump
  • Specifically designed for water features
  • 2 HP PSC Motor* (230V)
  • Energy efficient design, only draws 9 Amps
  • Built-In Thermal Protection w/ Auto-Reset
  • Provides added protection to keep your pump running
  • Continuous Duty Rated
  • For operating in the most rigorous of water features
  • Stainless Steel Motor Casing
  • Corrosion-resistant design for extended pump life
  • Vortex-Style Impeller
  • Easily pass solids up to 1"
  • Double Mechanical & Single Radial-Lip Shaft Seals
  • Provides maximum motor protection from leaks
  • 3" FPT Discharge
  • Allows for up to 16,000 GPH @ 5' Head lift
  • 19-Foot Power Cord w/ Bare Leads
  • Designed for hard-wired applications
  • 2-Year Limited Warranty
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
230 Volt
Running Amps
9
Thermal Protection
Yes
Power Cord Length
19 Feet
Pump
Gallons Per Minute
250 Gallons
Housing Material
Stainless Steel
Solids Handling Size
1 inch
Handles Solids
Yes
GPH @ 5 feet
16000
GPH @ 10 feet
15000
GPH @ 15 feet
13410
GPH @ 20 feet
11575
Discharge Port Size
3 Inch
Min Head
45 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
2 hp
Overview
Weight
55 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Depth
7.5 Inches
Product Width
11.75 Inches
Product Height
20.75 Inches
UPC
010121139985

Inlet Size
N/A
Style
GPM
250
Gallons
Inlet Size
N/A
GPM
250 Gallons
Features
Features
  • Little Giant WPG Series Submersible Pump
  • Specifically designed for water features
  • 2 HP PSC Motor* (230V)
  • Energy efficient design, only draws 9 Amps
  • Built-In Thermal Protection w/ Auto-Reset
  • Provides added protection to keep your pump running
  • Continuous Duty Rated
  • For operating in the most rigorous of water features
  • Stainless Steel Motor Casing
  • Corrosion-resistant design for extended pump life
  • Vortex-Style Impeller
  • Easily pass solids up to 1"
  • Double Mechanical & Single Radial-Lip Shaft Seals
  • Provides maximum motor protection from leaks
  • 3" FPT Discharge
  • Allows for up to 16,000 GPH @ 5' Head lift
  • 19-Foot Power Cord w/ Bare Leads
  • Designed for hard-wired applications
  • 2-Year Limited Warranty
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
230 Volt
Running Amps
9
Thermal Protection
Yes
Power Cord Length
19 Feet
Pump
Gallons Per Minute
250 Gallons
Housing Material
Stainless Steel
Solids Handling Size
1 inch
Handles Solids
Yes
GPH @ 5 feet
16000
GPH @ 10 feet
15000
GPH @ 15 feet
13410
GPH @ 20 feet
11575
Discharge Port Size
3 Inch
Min Head
45 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
2 hp
Overview
Weight
55 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Depth
7.5 Inches
Product Width
11.75 Inches
Product Height
20.75 Inches
UPC
010121139985
Product Specs
+
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
230 Volt
Running Amps
9
Thermal Protection
Yes
Power Cord Length
19 Feet
Pump
Gallons Per Minute
250 Gallons
Housing Material
Stainless Steel
Solids Handling Size
1 inch
Handles Solids
Yes
GPH @ 5 feet
16000
GPH @ 10 feet
15000
GPH @ 15 feet
13410
GPH @ 20 feet
11575
Discharge Port Size
3 Inch
Min Head
45 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
2 hp
Overview
Weight
55 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Depth
7.5 Inches
Product Width
11.75 Inches
Product Height
20.75 Inches
UPC
010121139985
