Lancaster Pump 2LSW7505-2 - 3/4 HP 22 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (2-Wire 230V)

Model:

2-2LSW7505-2

Write a Review
$592.00
Free Shipping
  Learn More About Free Freight
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.

Lancaster Pump 2LSW7505-2 - 3/4 HP 22 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (2-Wire 230V)
Lancaster Pump 2LSW7505-2 - 3/4 HP 22 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (2-Wire 230V)
Model: 2-2LSW7505-2
$592.00
Features
Specifications
Reviews
Product Q&A
Accessories
How-To Articles
Manuals
Share

Features

Inlet Size

N/A

Style

Deep Well

GPM

22 Gallons

  • SURVIVOR W-Series 22 GPM 4" Sub. Well Pump (2-Wire 230V)
  • For 4" I.D. or + Wells (<160'); 3-Wire Starting - No Control Box Required
  • 3/4 HP Lancaster HYDRO-FORCE Encapsulated Sub. Motor
  • Continuous duty rated, Induction run design w/ built-in starter
  • Stainless Steel Motor Casing & Splined Shaft End
  • Hermetically sealed, permanently lubricated, for greater heat exchange
  • Built-In Lighting Arrestors & Automatic Reset Overload
  • Provides surge and overhead protection for increased protection
  • 1.25" Stainless Steel Discharge Head, Motor & Cable Support
  • Superior strength & corrosion resistance for max life; replaceable CV
  • Balanced TeflonŽ Impregnated Thermoplastic Impellers
  • Reduces overall friction to maximize water flow
  • Fully-Enclosed Thermoplastic Diffusers & Stage Plates w/ SS Wear Surfaces
  • Each stage has separate comp. thrust washer for added protection
  • Heavy wall, High Quality SS Pump Casing & SS Intake Screen
  • Sized inside for perfect stage alignmen; wouldn't snap off during install
  • 3-Year Limited Warranty

Specifications

2-2LSW7505-2
Motor
Voltage
240 Volt
Running Amps
9.3
Wire
3-Wire
Pump
Gallons Per Minute
22 Gallons
Outlet Diameter
1-1/4"
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Plastic
Maximum PSI
65
Total Head Lift
160 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
0.75 hp
Overview
Assembly Required
Yes
Weight
28.9 Pounds
Consumer Warranty
3 Years
Product Length
24.16 Inches
Product Width
3.81 Inches

Reviews

Lancaster Pump 2-2LSW7505-2 Reviews & Ratings
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.

Product Q&A

(2)
Product Questions Answered by Jim, the Water Pump Expert
Question
+
Where is the motor manufactured?
John B.
from Pennsylvania
April 19, 2018
Answer
Most, if not all Lancaster deep well pumps listed on our website have the Hydro-Force motor which is built in Italy. They do also offer most of them with a Franklin motor which would be available as a special order.
Was this answer helpful?
Yes
2
No
0
Question
+
Do I need to buy a check valve or anything else with this pump?
Jim
from Connecticut
March 03, 2017
Answer
These pumps do include a built-in check valve. If however, your total vertical head lift exceeds 100 feet, you would need to install an additional check valve at every 100 foot level. You can also check out the Pump Manual for additional accessories that you may need to purchase. Please note that we only provide the pump. Any additional accessories needed for installation should be accessible at your local hardware or big box store.
Was this answer helpful?
Yes
1
No
1
