Koshin PB-68011 - 121 GPM (3") Submersible Utility Pump
Model: PB-68011
+
Share This Product
-
Product Description
-
Reviews
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Inlet Size
N/A
Style

GPM
121
Gallons
Inlet Size
N/A
Style
Utility
GPM
121 Gallons
Features
Features
- Heavy-Duty 3" Submersible Water Pump
- Provides a max output of up to 7286 GPH
- 2 HP 110/220V Single-Phase Motor
- Set @ 110V from the factory, can easily be changed in the field
- Compact Design w/ Top Mount Discharge
- Narrow width of pump (9 1/2") is great for tight applications
- Double Silicon Carbide Mechanical Seals
- Runs in an "oil" filled chamber of liquid paraffin
- Prevents damage from periods of dry running
- Built-In Thermal Protection
- Turns off the power supply in case of overload
- Cooler Running Motor
- Liquid is channeled through the outer wall
- Provides lower operating temperature to extend pump life
- 40' Uni-Body Power Cord
- Designed for water tightness in hard conditions
- 90-Day Limited Warranty
Specifications
Motor
Voltage
120/240 Volt
Running Amps
15
Pump
Gallons Per Minute
121 Gallons
Outlet Diameter
3"
Housing Material
Cast Iron
Impeller Material
Nylon
Total Head Lift
61 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Silicon Carbide
Overview
Weight
60 Pounds
Made in USA
No
Consumer Warranty
90 Days
Product Width
9.5 Inches
Product Height
25 Inches
Inlet Size
N/A
Style

GPM
121
Gallons
Inlet Size
N/A
Style
Utility
GPM
121 Gallons
Features
Features
- Heavy-Duty 3" Submersible Water Pump
- Provides a max output of up to 7286 GPH
- 2 HP 110/220V Single-Phase Motor
- Set @ 110V from the factory, can easily be changed in the field
- Compact Design w/ Top Mount Discharge
- Narrow width of pump (9 1/2") is great for tight applications
- Double Silicon Carbide Mechanical Seals
- Runs in an "oil" filled chamber of liquid paraffin
- Prevents damage from periods of dry running
- Built-In Thermal Protection
- Turns off the power supply in case of overload
- Cooler Running Motor
- Liquid is channeled through the outer wall
- Provides lower operating temperature to extend pump life
- 40' Uni-Body Power Cord
- Designed for water tightness in hard conditions
- 90-Day Limited Warranty
Specifications
Motor
Voltage
120/240 Volt
Running Amps
15
Pump
Gallons Per Minute
121 Gallons
Outlet Diameter
3"
Housing Material
Cast Iron
Impeller Material
Nylon
Total Head Lift
61 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Silicon Carbide
Overview
Weight
60 Pounds
Made in USA
No
Consumer Warranty
90 Days
Product Width
9.5 Inches
Product Height
25 Inches
Product Specs
+−
Specifications
Motor
Voltage
120/240 Volt
Running Amps
15
Pump
Gallons Per Minute
121 Gallons
Outlet Diameter
3"
Housing Material
Cast Iron
Impeller Material
Nylon
Total Head Lift
61 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Silicon Carbide
Overview
Weight
60 Pounds
Made in USA
No
Consumer Warranty
90 Days
Product Width
9.5 Inches
Product Height
25 Inches
