IPT Pumps 4S13XZR - 530 GPM (4") Electric Start Diesel Trash Pump w/ HATZ 1B50 Engine
Model: 4S13XZR
+
Share This Product
-
Product Description
-
Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Inlet Size
4"
Style
GPM
530
Gallons
Engine
Inlet Size
4"
Style
Trash
GPM
530 Gallons
Engine
Hatz
Features
Features
- IPT 4-Inch Portable, Diesel-Powered Centrifugal Trash Pump
- Easily handles leaves, debris, and solids up to 2" diameter
- Commercial Grade HATZ 1B50 517cc 4-Stroke Diesel Engine w/ Electric Start
- Compact, lightweight design provides long service life & easy starting
- Fuel efficient, provides longer runtime compared to gasoline engines
- Low Oil Alert
- Provides added protection against engine damage
- Cast Aluminum Construction w/ Cast Iron (Volute/Impeller) Wearparts
- Designed to resist abrasion which helps extend pump life
- 4-Inch Heavy-Duty Male NPT Suction & Discharge Ports
- Removable design allows ports to be replaced if damaged/stripped
- Adjustable Discharge Flange
- Versatile design, rotates in 90° increments for ease of use
- Silicon Carbide Mechanical Seal w/ Graphite Impregnated Seat & Viton Elastomers
- Provides exceptional abrasion and corrosion resistance for maximum performance
- One Tool Serviceability (Tool Included)
- Makes this pump extremely easy to service and pump maintenance
- Heavy Duty Steel Roll Frame w/ Vibration Dampening Feet
- Protects the pump/engine during transportation & operation
- Helps prevent "pump-walk" when pump is running
- Includes 4" Suction Strainer
- 1-Year Limited Warranty
Specifications
Motor
Battery Included
No
Pump
Gallons Per Minute
530 Gallons
Inlet Diameter
4"
Outlet Diameter
4"
Self Priming
Yes
Pump Head Material
Aluminum
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Silicon Carbide
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Suction Head
26 Feet
Total Head Lift
103 Feet
Engine
Engine Brand
Hatz
Starting System
12-Volt Button Start
Engine Cycles
4-Cycle
Low Oil Shutdown
Yes
CC
517 cc
Fuel Tank Size
1.32 Gallons
Run Time
1.8 Hours
Accessories
Tool Kit
Yes
Strainer
Yes
Overview
Weight
240 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31 Inches
Product Width
22.5 Inches
Product Height
23.6 Inches
UPC
726846540349
Inlet Size
4"
Style
GPM
530
Gallons
Engine
Inlet Size
4"
Style
Trash
GPM
530 Gallons
Engine
Hatz
Features
Features
- IPT 4-Inch Portable, Diesel-Powered Centrifugal Trash Pump
- Easily handles leaves, debris, and solids up to 2" diameter
- Commercial Grade HATZ 1B50 517cc 4-Stroke Diesel Engine w/ Electric Start
- Compact, lightweight design provides long service life & easy starting
- Fuel efficient, provides longer runtime compared to gasoline engines
- Low Oil Alert
- Provides added protection against engine damage
- Cast Aluminum Construction w/ Cast Iron (Volute/Impeller) Wearparts
- Designed to resist abrasion which helps extend pump life
- 4-Inch Heavy-Duty Male NPT Suction & Discharge Ports
- Removable design allows ports to be replaced if damaged/stripped
- Adjustable Discharge Flange
- Versatile design, rotates in 90° increments for ease of use
- Silicon Carbide Mechanical Seal w/ Graphite Impregnated Seat & Viton Elastomers
- Provides exceptional abrasion and corrosion resistance for maximum performance
- One Tool Serviceability (Tool Included)
- Makes this pump extremely easy to service and pump maintenance
- Heavy Duty Steel Roll Frame w/ Vibration Dampening Feet
- Protects the pump/engine during transportation & operation
- Helps prevent "pump-walk" when pump is running
- Includes 4" Suction Strainer
- 1-Year Limited Warranty
Specifications
Motor
Battery Included
No
Pump
Gallons Per Minute
530 Gallons
Inlet Diameter
4"
Outlet Diameter
4"
Self Priming
Yes
Pump Head Material
Aluminum
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Silicon Carbide
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Suction Head
26 Feet
Total Head Lift
103 Feet
Engine
Engine Brand
Hatz
Starting System
12-Volt Button Start
Engine Cycles
4-Cycle
Low Oil Shutdown
Yes
CC
517 cc
Fuel Tank Size
1.32 Gallons
Run Time
1.8 Hours
Accessories
Tool Kit
Yes
Strainer
Yes
Overview
Weight
240 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31 Inches
Product Width
22.5 Inches
Product Height
23.6 Inches
UPC
726846540349
Product Specs
+−
Specifications
Motor
Battery Included
No
Pump
Gallons Per Minute
530 Gallons
Inlet Diameter
4"
Outlet Diameter
4"
Self Priming
Yes
Pump Head Material
Aluminum
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Silicon Carbide
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Suction Head
26 Feet
Total Head Lift
103 Feet
Engine
Engine Brand
Hatz
Starting System
12-Volt Button Start
Engine Cycles
4-Cycle
Low Oil Shutdown
Yes
CC
517 cc
Fuel Tank Size
1.32 Gallons
Run Time
1.8 Hours
Accessories
Tool Kit
Yes
Strainer
Yes
Overview
Weight
240 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31 Inches
Product Width
22.5 Inches
Product Height
23.6 Inches
UPC
726846540349
