Barnes 3SF1074L - 1 HP Submersible Fountain Pump (200-240V)

Model:

109975

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Barnes 3SF1074L - 1 HP Submersible Fountain Pump (200-240V)
Barnes 3SF1074L - 1 HP Submersible Fountain Pump (200-240V)
Model: 109975
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Water Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

N/A

Style

Fountain

GPM

215 Gallons

  • Barnes 3SF1074L - 3SF-L Series 1 HP Submersible Fountain Pump (200-240V)
  • Designed for high-volume water features
  • Enamel Coated Cast Iron Construction
  • Helps prevent corrosion in aquatic conditions
  • 1 HP Oil-Filled, Permanent Split-Capacitor (PSC) Motor
  • Thermally protected, energy-efficient design, only draws 8.3 FLA
  • Cast Iron Vortex Impeller
  • Dynamically balanced design, provides up to a 35' head lift
  • Carbon/Ceramic/Buna-N Mechanical Seal
  • Assures maximum protection against pump failure
  • 416 Stainless Steel Shaft
  • Robust design helps increase life-span of pump
  • Oil-Lubricated, Upper & Lower Ball Bearings
  • Helps reduce vibration and provides quieter operation
  • 3" NPT (Female) Discharge
  • Allows this pump to provide up to 215 GPM of output
  • 15-Foot, 14/3 SOW Power Cord w/ Bare Lead
  • Requires hardwired connection for operation
  • 2-Year Limited Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

109975
specs product image PID-80852
Base
Base Material
Cast Iron
Motor
Voltage
240 Volt Single-Phase
Running Amps
8.3
Thermal Protection
Yes
Power Cord Length
15 Feet
Oil Free Motor
No
Starting Amps
25.8
Pump
Gallons Per Minute
215 Gallons
Outlet Diameter
3 Inch
Mechanical Seal Material
Ceramic Carbon
Housing Material
Cast Iron
Impeller Material
Cast Iron
Total Head Lift
35 Feet
Submersible
Yes
Engine
Horsepower
1 hp
Overview
Weight
95 Pounds
Consumer Warranty
2 Years
Product Length
13.99 Inches
Product Width
9.75 Inches
Product Height
18.63 Inches
