Tsurumi LB-480A - 62.4 GPM (2") Automatic Submersible Utility Pump
Model: LB-480A
4.6 out of 54.6 out of 54.6 out of 54.6 out of 54.6 out of 5
Number of Reviews(7)
Write a Review
$434.00
Free Shipping
Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships in 3-5 Days
Shipping to60601
Shipping Details
  • Expedited Shipping Available - Shipping rates calculated at Checkout. Learn More
*We currently CANNOT ship this product to Canada or any destination outside of the United States

Share
  • Product Description
  • 7
    Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Inlet Size
N/A
Style
Utility Pumps
GPM
62.4
Gallons
Inlet Size
N/A
Style
Utility
GPM
62.4 Gallons
Features
Features
  • Slimline Automatic Submersible Utility Pump w/ 2" Discharge
  • Allows pump to operate in spaces 8-3/4" diameter or larger
  • Molded Resin, Rubber Protected EL-1 Relay (Req. 4.5" - On)
  • No control panel/float, electrodes detect water to start pump
  • Internal timer eliminates frequent on/off in rough conditions
  • 2/3-HP 6.1-Amp Motor (12.5-Amp Starting) w/ Thermal Protection
  • Continuous duty rated, capable of pumping up to 3744 GPH
  • Top Discharge Provides Maximum Motor Cooling Efficiency
  • Provides max motor cooling efficiency & extended dry run time
  • Urethane Semi-Vortex Impeller & Wear Plates
  • Designed for maximum durability & pump performance
  • Double Inside Mechanical Seal w/ Silicon Faces
  • Provides the longest operational life of any seal available
  • Oil Lifter
  • Provides lubrication of the seal faces
  • V-Ring Seal Design
  • Protects mechanical seal from abrasive particles
  • 32' Power Cord
  • Great for outdoor applications
  • 2-Year Limited Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
6.1
Power Cord Length
32 Feet
Pump
Gallons Per Minute
62.4 Gallons
Outlet Diameter
2"
Mechanical Seal Material
Silicon Carbide
Housing Material
Thermoplastic
Impeller Material
Plastic
Solids Handling Size
.25 inch
Total Head Lift
39.5 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Silicon Carbide
Horsepower
0.66 hp
Overview
Weight
30 Pounds
Consumer Warranty
2 Years
Product Width
8.75 Inches
Product Height
11.25 Inches
UPC
894787000380
Additional Model Numbers
LB480A, LB-480A

Inlet Size
N/A
Style
Utility Pumps
GPM
62.4
Gallons
Inlet Size
N/A
Style
Utility
GPM
62.4 Gallons
Features
Features
  • Slimline Automatic Submersible Utility Pump w/ 2" Discharge
  • Allows pump to operate in spaces 8-3/4" diameter or larger
  • Molded Resin, Rubber Protected EL-1 Relay (Req. 4.5" - On)
  • No control panel/float, electrodes detect water to start pump
  • Internal timer eliminates frequent on/off in rough conditions
  • 2/3-HP 6.1-Amp Motor (12.5-Amp Starting) w/ Thermal Protection
  • Continuous duty rated, capable of pumping up to 3744 GPH
  • Top Discharge Provides Maximum Motor Cooling Efficiency
  • Provides max motor cooling efficiency & extended dry run time
  • Urethane Semi-Vortex Impeller & Wear Plates
  • Designed for maximum durability & pump performance
  • Double Inside Mechanical Seal w/ Silicon Faces
  • Provides the longest operational life of any seal available
  • Oil Lifter
  • Provides lubrication of the seal faces
  • V-Ring Seal Design
  • Protects mechanical seal from abrasive particles
  • 32' Power Cord
  • Great for outdoor applications
  • 2-Year Limited Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
6.1
Power Cord Length
32 Feet
Pump
Gallons Per Minute
62.4 Gallons
Outlet Diameter
2"
Mechanical Seal Material
Silicon Carbide
Housing Material
Thermoplastic
Impeller Material
Plastic
Solids Handling Size
.25 inch
Total Head Lift
39.5 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Silicon Carbide
Horsepower
0.66 hp
Overview
Weight
30 Pounds
Consumer Warranty
2 Years
Product Width
8.75 Inches
Product Height
11.25 Inches
UPC
894787000380
Additional Model Numbers
LB480A, LB-480A
Product Specs
+
Specifications
Motor
Voltage
120 Volt
Running Amps
6.1
Power Cord Length
32 Feet
Pump
Gallons Per Minute
62.4 Gallons
Outlet Diameter
2"
Mechanical Seal Material
Silicon Carbide
Housing Material
Thermoplastic
Impeller Material
Plastic
Solids Handling Size
.25 inch
Total Head Lift
39.5 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Silicon Carbide
Horsepower
0.66 hp
Overview
Weight
30 Pounds
Consumer Warranty
2 Years
Product Width
8.75 Inches
Product Height
11.25 Inches
UPC
894787000380
Additional Model Numbers
LB480A, LB-480A
