Little Giant W12G05S7-21P - 1/2 HP 12 GPM HP Deep Well Submersible Pump (2-Wire 115V)
Model: 558564
+
Share This Product
-
Product Description
-
9Reviews
-
4Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Inlet Size
N/A
Style

GPM
12
Gallons
Inlet Size
N/A
Style
Deep Well
GPM
12 Gallons
Features
Features
- 4" Submersible Deep Well Pump (2-Wire 115V)
- Ideal for use with 4" I.D. or larger wells
- Powered By Industry Standard Franklin Electric Motor
- Proven superior quality & performance ensuring quiet operation
- Hex Rubber Bearing w/ Extra-Large Surface
- Provides shaft stability and multiple flow channels
- Keeps small particles such as sand away from bearing surfaces
- Built-In Flomatic™ Check Valve
- Prevents backflow and ensures system pressure
- Removable Suction Screen
- Helps to prevent debris from clogging impellers
- Celcon® Disk
- Provides close tolerances for increased performance
- Ceramic Bearing Sleeve & Stainless steel Up-Thrust Washer
- Prevents excessive wear and provides added durability
- 1-1/4" NPT Thermoplastic Discharge Head
- Provides full-flow performance without the risk of corrosion
- 2-Year Warranty
- *Note* Installation Checklist Can Be Found On Manuals Tab
Specifications
Motor
Voltage
120 Volt
Wire
2-Wire
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
231 Feet
Submersible
Yes
Engine
Horsepower
0.5 hp
Overview
Weight
24 Pounds
Consumer Warranty
2 Years
Product Length
22.29 Inches
Product Width
3.9 Inches
UPC
010121118492
Inlet Size
N/A
Style

GPM
12
Gallons
Inlet Size
N/A
Style
Deep Well
GPM
12 Gallons
Features
Features
- 4" Submersible Deep Well Pump (2-Wire 115V)
- Ideal for use with 4" I.D. or larger wells
- Powered By Industry Standard Franklin Electric Motor
- Proven superior quality & performance ensuring quiet operation
- Hex Rubber Bearing w/ Extra-Large Surface
- Provides shaft stability and multiple flow channels
- Keeps small particles such as sand away from bearing surfaces
- Built-In Flomatic™ Check Valve
- Prevents backflow and ensures system pressure
- Removable Suction Screen
- Helps to prevent debris from clogging impellers
- Celcon® Disk
- Provides close tolerances for increased performance
- Ceramic Bearing Sleeve & Stainless steel Up-Thrust Washer
- Prevents excessive wear and provides added durability
- 1-1/4" NPT Thermoplastic Discharge Head
- Provides full-flow performance without the risk of corrosion
- 2-Year Warranty
- *Note* Installation Checklist Can Be Found On Manuals Tab
Specifications
Motor
Voltage
120 Volt
Wire
2-Wire
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
231 Feet
Submersible
Yes
Engine
Horsepower
0.5 hp
Overview
Weight
24 Pounds
Consumer Warranty
2 Years
Product Length
22.29 Inches
Product Width
3.9 Inches
UPC
010121118492
Product Specs
+−
Specifications
Motor
Voltage
120 Volt
Wire
2-Wire
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
231 Feet
Submersible
Yes
Engine
Horsepower
0.5 hp
Overview
Weight
24 Pounds
Consumer Warranty
2 Years
Product Length
22.29 Inches
Product Width
3.9 Inches
UPC
010121118492
Product Q&A
(4)
+−

Search Product Q&A's
Answered by Jim, the Water Pump Expert
+−
In have 4 inch ID pvc well casing ..your product description says it will fit. What is the width of the pump?
Vince
from Indiana
June 16, 2016
Answer
The width of these pumps average 3.90" and WILL fit inside a 4" well casing.
If you have any other questions, please let me know.
If you have any other questions, please let me know.
Was this answer helpful?
Yes

3
No

0
+−
I plan to replace a 30 yer old pump that is at 200 ft. and lower the new pump to 250 ft in a 400 ft deep well. Will I need to a check valve mid way up as well as at the well head?
Ken G
from California
July 27, 2015
Answer
Most submersible deep well pumps include a built-in check valve at the discharge port of the pump and It is recommended that additional spring loaded in-line check valves be installed in the drop pipe @ 200ft intervals only.
Was this answer helpful?
Yes

3
No

0
+−
what parts are involved with submersible pumps that can fail and breakdown or if it doesn't work you just have to replace the entire pump?
Sal
from New York
January 22, 2014
Answer
When it comes to 2-wire deep well submersible pumps, the pump starting controls are located inside the pump. Any of these components can fail and cause the pump to become inoperable. By installing a 3-wire pump, those components would be located inside a CONTROL BOX, making repairs much easier when failure of these components are the cause of your pump not operating. Of course if the pump has failed due to burnt motor windings or some other cause, would would still need to pull and replace the pump, but you would have a better understanding of the pump status when the pump starting components are above ground as opposed to 50-500 feet or more, below ground.
Was this answer helpful?
Yes

2
No

0
+−
Hi Jim,
I have a well with 4 inch bore (pipe with 4" ID) and want to switch to a 4" submirsible pump. my question is with a 4" submirsible pump how much clearance do i need.
does the bore not need to be much larger then 4" otherwise how will the pump suck water if the will pipe walls are touching the pump.
Javid A
from California
January 06, 2014
Answer
Thank you for your interest in Water Pumps Direct. The actual pumps measure 3.90" in diameter and will fit inside a 4" ID well casing.
Was this answer helpful?
Yes

0
No

0
