Red Lion 1 HP Deep Well Submersible Pump (3-Wire 230V) w/ Control Box

Close
Red Lion Water Pumps and Accessories
Model: RL12G10-3W2V
(Based on expert analysis, manufacturer ratings and customer reviews)
4.8 out of 54.8 out of 54.8 out of 54.8 out of 54.8 out of 5
24 Reviews
Share This Product
Plus 1 This Product
Tweet This Product
Pin It!
In-Stock In-Stock
Ships Tuesday, Jul 25th

Estimate Arrival
$469.99

StoreShippingPriceShop

In-Stock
Free Shipping
$469.99
No Sales Tax*
(Except IL)
Buy

$469.99
No Sales Tax*
(Except IL)
Visit Site

$469.99
(as of 06:57 CST - Details)
Sales Tax Extra
Visit Site

$485.62
Sales Tax Extra
Visit Site

$485.62
Sales Tax Extra
Visit Site
  • Features
  • Specs
  • 6
    Q&A
  • 24
    Reviews
  • Articles
  • Shipping
  • Accessories

Inlet Size
N/A
Style
GPM
12
Gallons
4" Submersible Deep Well Pump

Ideal for use with 4" I.D. or larger wells

Powered By Industry Standard 3-Wire 230V Motor
Proven superior quality & performance ensuring quiet operation

Hex Rubber Bearing w/ Extra-Large Surface
Provides shaft stability and multiple flow channels
Keeps small particles such as sand away from bearing surfaces

Built-In Check Valve
Prevents backflow and ensures system pressure

Built-In Suction Screen
Helps to prevent debris from clogging impellers

1-1/4" NPT Thermoplastic Discharge Head
Provides full-flow performance without the risk of corrosion

Includes Industry Standard Red Lion Control Box
Eliminates confusion for control box selection


Motor
Voltage
240 Volt
Wire
3-Wire
Engine
Continuous Operation
Yes
Horsepower
1 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
380 Feet
Maximum PSI
80
Submersible
Yes
Accessories
Control Box
Yes
Overview
Made in USA
No
Weight
32 Pounds
Consumer Warranty
3 Years
UPC
010121141834
Model
RL12G10-3W2V
Download Documents
Need Help? Ask Our Experts.
View Accessories For This Product.
Read Reviews
How-To Library
Subject: Store ID: Product ID: Data Category: Brand Category:

*Ask Jim about the Red Lion RL12G10-3W2V. Sorry, no repair questions:


*Name:


*State:


*Email:


 Receive Weekly How-To Tips & Specials


*Required Field Submit
  6 Questions
Q: In have 4 inch ID pvc well casing ..your product description says it will fit. What is the width of the pump?
by Vince from Indiana on June 16, 2016

A: The width of these pumps average 3.90" and WILL fit inside a 4" well casing.
If you have any other questions, please let me know.
by Jim, Product Expert
Q: I plan to replace a 30 yer old pump that is at 200 ft. and lower the new pump to 250 ft in a 400 ft deep well. Will I need to a check valve mid way up as well as at the well head?
by Ken G from California on July 27, 2015

A: Most submersible deep well pumps include a built-in check valve at the discharge port of the pump and It is recommended that additional spring loaded in-line check valves be installed in the drop pipe @ 200ft intervals only.
by Jim, Product Expert
Q: Does wiring come with the pump
by Dwight B from Louisiana on June 11, 2015

A: The Red Lion deep well pumps include 12" - 18" of wire and a waterproof splice kit and instructions. All other wiring does need to be supplied by you or your installer.
by Jim, Product Expert
Q: what guage wire should be run to this pump if set at two hundred feet
by Billy from West Virginia on June 22, 2014

A: Thank you for your interest in Water Pumps Direct. Information on the wiring gauge based on the distance for all Red Lion pumps can be found on page 3 of the OWNER'S MANUAL.
by Jim, Product Expert
Q: Jose, what is the amperage of a Red Lion 1.5 220 deep well pump.
by Cliff from South Carolina on May 11, 2013

A: Unfortunately, we do not have access to the amp ratings for these pumps. Please call Red Lion tech support at 888-956-0000 for further assistance.
by Jim, Product Expert
Q: what is the purpose of the control box and can it be eliminated?
by Armand from Ohio on July 09, 2012

A: Three wire submersible motors require a control box. Control boxes contain a starting relay, starting capacitors and in some cases overload protectors. Two wire submersible motors have these components built into them and do not require a control box.

One benefit of using a three wire motor with a control box is that some of the components that are subject to failure are located above ground where you can get to them without pulling the pump.

Control boxes should never be mounted in direct sunlight or in locations that are extremely hot, this causes the capacitor life to be shortened and can cause nuisance overload trips. Do not mount the control box in a humid location such as a damp well pit since voltage breakdown and corrosion will accelerate component failure in this condition.

Control boxes are designed for vertical, upright mounting only. Any other position will affect the operation of voltage sensing relays in larger sizes and may result in water leakage.
by Jim, Product Expert
Red Lion RL12G10-3W2V Reviews & Ratings
Overall Rating
Features
5/5
Quality
5/5
Performance
5/5
Value
5/5
Overall
4.8 out of 54.8 out of 54.8 out of 54.8 out of 54.8 out of 5
Pros
I'd Buy It Again (7)
Price (4)
Quiet (2)
Easy To Use (2)
High Quality (2)
Cons
None (1)
some plastic rather than... (1)
No bad issues at this ti... (1)
Expensive (1)
95% of respondents would recommend this product to a friend
24 Reviews  Sort by

William S.
Jemez Springs, NM
Purchased from Water Pumps Direct
Purchased 4/8/15
Total Reviews
2 Reviews
Most Helpful Positive Review
REVIEWED
NOV.
03
2016
5 out of 55 out of 55 out of 55 out of 55 out of 5
Working Great
Been using this pump for several years and is working great. Had problems with pressure tank and broke the water line fitting 40 ft above the pump.I think do to much cycling. This replaced a very old Red Lion and also a recommended pump by others I know
Pros: I'd Buy It Again, Durable, Fast, Reliable
William Recommends This Red Lion Product
Was this review helpful?
11
Frankie H.
Brownwood, TX
Purchased from Water Pumps Direct
Purchased 11/17/16
REVIEWED
DEC.
18
2016
4 out of 54 out of 54 out of 54 out of 54 out of 5
Excellent Sump & Excellent Service From Water Pumps Direct
The product performed as it should.
Pros: I'd Buy It Again, Easy To Use, High Quality, Easy To Store
Cons: Expensive
Frankie Recommends This Red Lion Product
Frankie's Experience With Water Pumps Direct
Web Site
4/5

Service
5/5

Shipping
4/5
"The original pump proved to be faulty and they worked with me to replace it."
 more
Was this review helpful?
00
Paul L.
Tucson, AZ
Purchased from Water Pumps Direct
Purchased 9/12/16
REVIEWED
OCT.
05
2016
5 out of 55 out of 55 out of 55 out of 55 out of 5
Worked Well
This pump was used to replace a like unit that failed after 1 - 1/2 years. This new pump has worked well for 2 months so far and perform very well. The failed unit has been replaced by warranty. Both Pumps Direct and Franklin (the manufacturer) were very good to deal with on the warranty claim.

I would buy this pump again from Water Pumps Direct.
Paul Recommends This Red Lion Product
Was this review helpful?
00
Robert P.
Del Rio, TX
Purchased from Water Pumps Direct
Purchased 4/3/17
Total Reviews
2 Reviews
REVIEWED
APR.
25
2017
5 out of 55 out of 55 out of 55 out of 55 out of 5
Red Lion 1 Hp Deep Well Submersible Pump
Easy to install as I am a plumber that can do deep wells/ fast shipping/ it been in the hole now about 3 weeks and working great/ pressure 40 to 60 psi. I have 2 89 gal. tank and it fills them fast/ I bought this for my country home
Pros: I'd Buy It Again, Price, Easy To Use, Fast
Cons: No bad issues at this time
Robert Recommends This Red Lion Product
Robert's Experience With Water Pumps Direct
Web Site
5/5

Service
5/5

Shipping
5/5
"I expect this pump to out last my previous pumps which were not Red Lion pumps."
 more
Was this review helpful?
01
Ed B.
Mountainair, NM
Purchased from Water Pumps Direct
Purchased 2/12/17
REVIEWED
MAR.
10
2017
4 out of 54 out of 54 out of 54 out of 54 out of 5
Replacement For Grundfos Submersible
I had a Grundfos submersible go out after 20 years. I could source a new one locally, but could not find performance data showing GPM at 60# cutoff to determine replacement pump without pulling pump first. Performance curve charts aren't enough for me. Having a manual hand pump down same casing, I wasn't gonna do that and be completely without water.

So, I researched several different manufacturers and found that for my needed GPM at 60# cutoff (to satisfy wife's desire to over-water... more
Pros: I'd Buy It Again, Price, Quiet
Cons: some plastic rather than all stainless
Ed Recommends This Red Lion Product
Was this review helpful?
01
Marvin
Purchased from Water Pumps Direct
Purchased 4/21/13
REVIEWED
MAY.
25
2013
3 out of 53 out of 53 out of 53 out of 53 out of 5
Pump Threads
My initial impression was favorable but then I tried to screw my pipe adapter into the pump and found the threads in the plastic female threads of the pump were distorted or machined wrong making screwing the adapter into the pump a problem. The end result was I was unable to get many threads engaged. I am hoping that enough to hold the pump were engaged. I have bought quite a few products made in China and fit and quality is usually poor.
Was this review helpful?
50
Wendy Y.
Aiken, SC
Purchased from Water Pumps Direct
Purchased 2/20/13
REVIEWED
APR.
09
2013
5 out of 55 out of 55 out of 55 out of 55 out of 5
Water Outage Resolved...
We were out of water for about a month. We were using the neighbors water spigot to flush, wash dishes, bathe and hand wash clothes. We're not too proud to admit that, and did well considering some people out there can't live without a cell phone let alone survive without electric pumps and such.

Anyway, my husband contacted Water Pumps Direct, and ordered a Deep Well pump and it arrived! We were ecstatic and "pumped" with this arrival. We had a local resident well guy pull the... more
Was this review helpful?
61
Richard S.
Monroe, NY
Purchased from Water Pumps Direct
Purchased 5/27/14
REVIEWED
JUL.
08
2014
5 out of 55 out of 55 out of 55 out of 55 out of 5
Worked Right Out Of The Box
I had a 1 hp pump in my well that lasted 13 years and it finally went. Bought one from Lowe's and it lasted 2 days. I found the Red Lion pump on line from Water Pumps Direct and it works great. 40-60 lbs of pressure and the pump has a 3 year warranty and it comes with the control box.. Lowes was 1 year. I would not but a pump from Lowes or Home Depot again.
Pros: Durable, Price, High Quality, I'd Buy It Again
Richard Recommends This Red Lion Product
Was this review helpful?
51
Richard J.
Shelbyville, IL
Purchased from Water Pumps Direct
Purchased 7/21/14
REVIEWED
SEP.
01
2014
5 out of 55 out of 55 out of 55 out of 55 out of 5
Irrigation Pump
Using this pump for irrigation. Pushing it up 130 feet through 750 feet of 2-inch sched. 40 and still pushing better than 12 gal./min.
Pros: I'd Buy It Again, Quiet, Good Instructions
Richard Recommends This Red Lion Product
Was this review helpful?
41
Frank
Placerville, CA
Purchased from Water Pumps Direct
Purchased 4/1/13
REVIEWED
MAY.
15
2013
5 out of 55 out of 55 out of 55 out of 55 out of 5
I've Got Water!!!
This is the first time I've set a pump. Measured the well to be 255', and set the pump at 220'. Followed the wiring diagram and the piping diagram and to my surprise it worked! Not only that...It works very well! Would like to thank WPD for following up on the shipping damage to the control box ...The replacement arrived in 2 days. Thanks Guys @ WPD...
Was this review helpful?
30
Randall G.
Kingman, AZ
Purchased from Water Pumps Direct
Purchased 7/28/15
REVIEWED
AUG.
19
2015
5 out of 55 out of 55 out of 55 out of 55 out of 5
Exceeded My Expectations
This was the first time for me installing my own well. Static water is a 115 ft, well depth 203 ft and I set the pump at 150 ft.
So far so good, performance sheet states I should be getting 14 gpm but we are getting 20 gpm. Im running 1.25 schedule 80 pvc and have not completed the installation to all the property outlets. But at this time Im extremely pleased with the performance, time will tell. Also saving a few hundred dollars on a quality pump always helps.
Randall Recommends This Red Lion Product
Was this review helpful?
20
