Features
Inlet Size
1-1/4 Inch
Style
Convertible Jet
GPM
20 Gallons
1 HP Convertible Jet Pump
Ideal for use in shallow wells (less than 25’)
Ideal for use in deep wells (25’ to 90’)
Heavy-Duty Cast Iron Construction
Built for years of service and reliability
115/230 Volt Heavy-Duty Century Motor
Voltage selector for simple connection to existing power source
Includes Factory Pre-Set 30/50 Pressure Switch
Produces up to 50 PSI with automatic shut-off
Glass-Filled Thermoplastic Impeller & Diffuser
For high performance and efficient water flow
Additional Specs
1-1/4" FNPT - Intake / 1" FNPT - Discharge
16.4A @ 115 V
8.2A @ 230 V
3-Year Warranty
Specifications
602038
General Information
Product Category
Water Pump
Motor
Voltage
120/240 Volt
Pump
Gallons Per Minute
20 Gallons
Inlet Diameter
1-1/4 Inch
Outlet Diameter
1 Inch
Pump Housing Drain
Yes
Housing Material
Cast Iron
Impeller Material
Plastic
Suction Head
90 Feet
Maximum PSI
87
Submersible
No
Engine
Horsepower
1 hp
Overview
Product Category
Water Pump
Weight
37 Pounds
Consumer Warranty
2 Years
UPC
010121122833
Additional Model Numbers
RJC-100, 602038
Reviews
(14)
Red Lion 602038 Reviews & Ratings
Customer Photos and Videos
Product Q&A
(1)
Product QuestionsAnswered by Jim, the Water Pump Expert
What size tank do I need with this pump?
Byron T.
from Georgia
May 11, 2017
Answer
Tanks for shallow or deep well applications are typically sized based on a minimum 3 times your GPM requirements. So for example, if you NEED 12GPM, you should have a minimum 36 gallon pressure tank.
Was this answer helpful?
Yes
10
No
1
