The Red Lion 1 hp deep well submersible pump (2-wire 230v) is available for purchase today.

Read Red Lion RL12G10-2W2V reviews before checking out.


Get the best deal on your new Red Lion RL12G10-2W2V.

No coupon code required.

Red Lion 1 HP Deep Well Submersible Pump (2-Wire 230V)

Close
Red Lion Water Pumps and AccessoriesModel: RL12G10-2W2V
(Based on expert analysis, manufacturer ratings and customer reviews)
4.8 out of 54.8 out of 54.8 out of 54.8 out of 54.8 out of 5
12 Reviews
Share This Product
Plus 1 This Product
Tweet This Product
Pin It!
In-Stock In-Stock
Ships Tuesday, Dec 13th

Estimate Arrival
$474.99

StoreShippingPriceShop

In-Stock
Free Shipping
$474.99
No Sales Tax*
(Except IL)
Buy

$474.99
No Sales Tax*
(Except IL)
Visit Site

$474.99
(as of 06:32 CST - Details)
Sales Tax in 26 states
Visit Site

$592.22
Sales Tax Extra
Visit Site

$481.99
Sales Tax Extra
Visit Site
  • Features
  • Specs
  • 7
    Q&A
  • 12
    Reviews
  • Articles
  • Shipping
  • Accessories

Outlet Size
1-1/4"
Style
Deep Well
GPM
12
Gallons
4" Submersible Deep Well Pump (2-Wire 230V)

Ideal for use with 4" I.D. or larger wells

Powered By Industry Standard Motor
Proven superior quality & performance ensuring quiet operation

Hex Rubber Bearing w/ Extra-Large Surface
Provides shaft stability and multiple flow channels
Keeps small particles such as sand away from bearing surfaces

Built-In Check Valve
Prevents backflow and ensures system pressure

Built-In Suction Screen
Helps to prevent debris from clogging impellers

1-1/4" NPT Thermoplastic Discharge Head
Provides full-flow performance without the risk of corrosion


Need Help? Ask Our Water Pump Experts.
Motor
Voltage
240-Volt
Wire
2-Wire
Engine
Continuous Operation
Yes
HP
1 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
380 Feet
Maximum PSI
80
Overview
Made in USA
No
Weight
28 Pounds
Consumer Warranty
3 Years
UPC
010121141803
Model
RL12G10-2W2V
Download Documents
Need Help? Ask Our Water Pump Experts.
View Accessories For This Product.
Read Reviews
How-To Library

*Ask Jim about the Red Lion RL12G10-2W2V. Sorry, no repair questions:


*Name:


*State:


*Email:


 Receive Weekly How-To Tips & Specials


*Required Field Submit
  7 Questions
Q: In have 4 inch ID pvc well casing ..your product description says it will fit. What is the width of the pump?
by Vince from Indiana on June 16, 2016

A: The width of these pumps average 3.90" and WILL fit inside a 4" well casing.
If you have any other questions, please let me know.
by Jim, Product Expert
Q: I'm replacing an old ('86) Red Jacket 3/4hp Submersible pump. It's a 2-wire 230v pump, but it was installed with a control box and worked for a long time. The replacement, to avoid a full rewire, is a 2-wire 1hp RL12G10-2W2V. I know that these systems have internal starting caps, so I have 2 questions.

1) Is there any benefit to having a control box with a 2 wire system?

2) [if so] Can I reuse the same control box that is marked for 3/4hp Franklin pump?

by Justin H from Missouri on August 14, 2015

A: Thank you for your interest in Water Pumps Direct. The ONLY difference between a 2-wire and 3-wire pump is that the 3-wire pump requires the control box, which houses the pump relay, overload and capacitor. The 2-wire pumps include all starting components inside the pump. Thus, if you are installing a 2-wire pump, there is no need for the control box and you should NOT include it in any portion of your installation.

If one was to use a control box that was already installed, you only need to insure that the horsepower (HP) rating of the pump and control box match.
by Jim, Product Expert
Q: I plan to replace a 30 yer old pump that is at 200 ft. and lower the new pump to 250 ft in a 400 ft deep well. Will I need to a check valve mid way up as well as at the well head?
by Ken G from California on July 27, 2015

A: Most submersible deep well pumps include a built-in check valve at the discharge port of the pump and It is recommended that additional spring loaded in-line check valves be installed in the drop pipe @ 200ft intervals only.
by Jim, Product Expert
Q: Does wiring come with the pump
by Dwight B from Louisiana on June 11, 2015

A: The Red Lion deep well pumps include 12" - 18" of wire and a waterproof splice kit and instructions. All other wiring does need to be supplied by you or your installer.
by Jim, Product Expert
Q: what parts are involved with submersible pumps that can fail and breakdown or if it doesn't work you just have to replace the entire pump?
by Sal from New York on January 22, 2014

A: When it comes to 2-wire deep well submersible pumps, the pump starting controls are located inside the pump. Any of these components can fail and cause the pump to become inoperable. By installing a 3-wire pump, those components would be located inside a CONTROL BOX, making repairs much easier when failure of these components are the cause of your pump not operating. Of course if the pump has failed due to burnt motor windings or some other cause, would would still need to pull and replace the pump, but you would have a better understanding of the pump status when the pump starting components are above ground as opposed to 50-500 feet or more, below ground.
by Jim, Product Expert
Q: Does this pump have a grounding wire beside the two hot wires?
by Dan S from New York on August 17, 2013

A: Thank you for your interest in Water Pumps Direct. The Red Lion model RL12G07-2W2V, like any other 2-Wire deep well pump, would have two line voltage wires and one ground wire so you would have three wires total.
by Jim, Product Expert
Q: I need to replace my deep submersible pump and I would like to get your recommendation on what size I should get. The one that is in there now is a myers 3/4 hp 2 wire pump. I think it is a 10 GPM. I have had it for almost 9 years but with an irrigation installed now which the pump supplies both house and irrigation. My irrigation has 8 zones with 3 heads on each zone which usually runs 20 minutes on each zone with a break of an hour between zones 1 2 3 4 5 and then 6 7 8. The well is 240 feet down but I'm not sure if that's where the pump is or where the head static level is. I would like to increase the HP to a 1hp and GPM to 20. Would this work better than the one I have???
by Duane from New Hampshire on April 13, 2013

A: Thank you for visiting Water Pumps Direct. Before I could make any recommendation, I would need to know the following:

What is the depth of the well and at what depth is the pump set?

How much distance and vertical rise between the well head and the house and furthest sprinkler head?

What is the GPM and PSI rating for each head in each zone and how many heads would be operating at once?

By simply increasing your HP, you might solve your problem, but if you can answer the questions I have posed to you, I could make sure that you ARE solving your problem.
by Jim, Product Expert
Red Lion RL12G10-2W2V Reviews & Ratings
Overall Rating
Features
5/5
Quality
5/5
Performance
5/5
Value
5/5
Overall
4.8 out of 54.8 out of 54.8 out of 54.8 out of 54.8 out of 5
Pros
I'd Buy It Again (3)
Easy To Store (1)
Price (1)
Cons
None to display.
100% of respondents would recommend this product to a friend
12 Reviews  Sort by

Jeff B.
Hemet, CA
Purchased from Water Pumps Direct
Purchased 9/7/16
Most Helpful Positive Review
REVIEWED
SEP.
29
2016
5 out of 55 out of 55 out of 55 out of 55 out of 5
Buy It
Started first time, every time. This is the pump to have, if it fits your well demands. I personally feel it's bullet proof.
Jeff Recommends This Red Lion Product
Was this review helpful?
00
Hampton H.
Purchased from Water Pumps Direct
Purchased 6/23/16
REVIEWED
JUL.
25
2016
5 out of 55 out of 55 out of 55 out of 55 out of 5
It's Working Like A Champ
I installed it myself with no previous experience and had no problems. So far, so good.
Hampton Recommends This Red Lion Product
Was this review helpful?
00
Matt H.
Mcminnville, TN
Purchased from Water Pumps Direct
Purchased 6/22/16
REVIEWED
JUL.
14
2016
5 out of 55 out of 55 out of 55 out of 55 out of 5
Works Great
We replaced our older pump with this one and it works great. Easy to install and hook up. Would strongly recommend it.
Matt Recommends This Red Lion Product
Was this review helpful?
00
Steve H.
Franklin, MA
Purchased from Water Pumps Direct
Purchased 3/11/16
REVIEWED
MAY.
01
2016
5 out of 55 out of 55 out of 55 out of 55 out of 5
Works Great
I've only had it a couple of months but it works great..Irrigation system works better than ever.
Steve Recommends This Red Lion Product
Was this review helpful?
00
William B.
Port Townsend, WA
Purchased from Water Pumps Direct
Purchased 8/9/15
REVIEWED
AUG.
31
2015
5 out of 55 out of 55 out of 55 out of 55 out of 5
Pump Is Installed
Installed pump 7 days ago at 160 feet in new well.

The water cleared up after about 200 gallons pumped out. I used the Red Lion website to pick the correct pump for this depth.
Two wire is easy to connect.

But I didn't get a receipt for the warranty record.
William Recommends This Red Lion Product
Was this review helpful?
10
Gale B.
Coldwater, MS
Purchased from Water Pumps Direct
Purchased 7/9/13
REVIEWED
JUL.
31
2013
4 out of 54 out of 54 out of 54 out of 54 out of 5
Price & Stated Gpm Good
I ordered the pump for a spare, let a friend have 1 hp new red devil pump. I have two wells and like to keep a spare. I'm sure the three year warranty won't apply if I don't install it until a later date. Both my wells are working fine right now one or both could go out at any time though. Expect the Red Lion to perform adequately when needed.
Pros: Price, Easy To Store
Gale Recommends This Red Lion Product
Gale Would Recommend Water Pumps Direct To A Friend
Web Site
5/5

Service
5/5

Shipping
5/5
"Very good!"
 more
Was this review helpful?
10
Forrest Patterson
Hartland, MI
Purchased from Water Pumps Direct
Purchased 6/1/13
REVIEWED
JUN.
22
2013
5 out of 55 out of 55 out of 55 out of 55 out of 5
Good Well Pump
So far so good.
Pros: I'd Buy It Again
Forrest Recommends This Red Lion Product
Was this review helpful?
21
Wayne Rowley
Auburn, CA
Purchased from Water Pumps Direct
Purchased 10/10/14
REVIEWED
OCT.
31
2014
5 out of 55 out of 55 out of 55 out of 55 out of 5
Lost Sales
The Red Lion pump is working to my satisfaction, however when I read the installation instructions, I should have had the proper control box. I would have purchased the control box from you if someone would have advised me.

The speed at which I received the shipment was excellent, and I commend you. I look forward to dealing with you in the future.
Wayne Recommends This Red Lion Product
Was this review helpful?
00
Robert H.
Newcastle, WY
Purchased from Water Pumps Direct
Purchased 11/27/13
REVIEWED
DEC.
20
2013
5 out of 55 out of 55 out of 55 out of 55 out of 5
Livestock Well In Winter Pasture
Installed pump in a livestock water well connected to a timer. Watering 300 head of cows in a remote area in winter pasture. Trust this pump will last 3 or 4 years.
Pros: I'd Buy It Again
Robert Recommends This Red Lion Product
Was this review helpful?
11
Ryan F.
Johnstown, NY
Purchased from Water Pumps Direct
Purchased 10/28/13
REVIEWED
NOV.
18
2013
5 out of 55 out of 55 out of 55 out of 55 out of 5
Great
Love it, great pump! Great price, and prompt delivery.
Pros: I'd Buy It Again
Ryan Recommends This Red Lion Product
Was this review helpful?
11
Luke P.
Grain Valley, MO
Purchased from Water Pumps Direct
Purchased 11/13/15
REVIEWED
DEC.
04
2015
5 out of 55 out of 55 out of 55 out of 55 out of 5
First Words Wow!
So this was ordered to replace the well pump @ the family lake house. The well depth 310 ft bottom of the well is 325. Used the wire isolator kit offered tested & no fail worked right the first time. The instructions that come with the pump you could know nothing about how a pump goes in & it is correct & clear on every step. Test ran day after install adjusted new presure switch. Awesome presure test . Will put to full use next summer .
Luke Recommends This Red Lion Product
Luke's Experience With Water Pumps Direct
Web Site
5/5

Service
5/5

Shipping
5/5
"Hands down best online company for plumbing supplys! Received pump in two days !"
 more
Was this review helpful?
01
